long time experience

with this newly designed models even experienced users of baling presses like paper industry or recycling plants are convinced by the high quality and reliability of these machines. highly compacted and stackable bales for an optimal truck loading are the best proof for the excellent efficiency of these channel balers. this continuous, reliable machine in combination with an optimal feeding attachment together provide a modern and future-oriented waste handling and is therefore perfectly equipped for every logistic requirement. optimal designed hydraulic blocks, an ideal cutting system and the patented automatic tying unit guarantee maximum pressing speed together with low energy consumption.

  • bale size: 800×750 mm
  • bale weight: 200 – 400 kg
  • press performance: 160 – 270 m³/h
  • compacting pressure: 320 – 420 kN

fields of application

channel baling presses of the range APK-C are suitable for edge trims from paper and plastics, fragments from cardboard production, various shredded materials, labels, paper and plastic bags from food or animal feedstuff production, trims from synthetic products, fibers, PET-bottles, wooden fruit crates, etc.

APK-C download brochure (PDF)
  • the big roller guide of the press plate allows to take high pressure
  • changeable bottom parts are made of wear resistant HARDOX
  • energy efficiency and high throughput due to ideal designed cutting knives
  • patented fully automatic tying system DRILLFIX guarantees a continuous and failure-free operation
  • hydraulic unit is equipped with a self regulating low noise axial pump including automatic switch off
  • inspection doors on both sides guarantee a quick and safe maintenance
  • key transfer system for maximum operator safety
  • different hoppers for variable areas of application – even with control sensor for overfilling
  • automatic pressure-controlled channel adjustment on three sides guarantee high bale weights
  • duo-switch with 2 or optionally 6 pressure levels for optimal operating of different material and frequent material changes
  • big range of additional equipment
  • high durability and reliability based on our quality standards
technical data
Model APK-C 32-1250APK-C 42-800APK-C 42-1250
compression force kN 320420420
motor kW 15 | 22 15 | 22 | 30 15 | 22 | 30
specific pressure force N/cm² 537070
Theoretical power m³/h 160 | 215145 | 180 | 240130 | 160 | 270
loading aperture mm 1250x740800x7401250x740
loading volume 0,90,60,9
Bale size mm 800x750800x750800x750
bale weight kg 200-350*250-400*250-400*
binding 3v or 3h4v or 4h4v or 4h
2h optional 2h optional2h optional
dimensions lxwxh mm 7300x1900x33006750x1900x33007300x1900x3300
weight kg 810083008900
technical data subject to change / further information see brochure or on request

* depending on material for a bale length of 1200mm
